GE605 Backhoe
6' 4" digging depth, the GE605 backhoe can mount on your tractor to handle any landscaping or dirt excavating job.
Price: $7,795
The $250 deposit holds this item for 10 business days and counts toward the purchase price. If you walk away, the deposit is forfeited. Sold as-is.
About the GE605 Backhoe
6' 4" digging depth, the GE605 backhoe can mount on your tractor to handle any landscaping or dirt excavating job. For rural property owners, farmers or small businesses, this rugged backhoe is ready to sink its teeth into any task you give it.
New Wallenstein equipment is supplied through Valtek, built by EMB Manufacturing in St. Clements, Ontario. Tell us what you run and we will confirm fitment, price and lead time.
Features
- Curved Boom
- Greaseable Pins
- Hydraulic Stabilizers
- Replaceable Teeth
- Subframe Mounting
- Swing Cushioning
Specifications
| Digging Depth | 6' 4" (193 cm) |
| Engine HP Range (Tractor) | 15 - 35 |
| Required Hydraulic Flow | 4 - 12 gpm (15 - 45 lpm) |
| Stabilizer Width (Spread) | 72" (183 cm) |
| Main Boom Cylinder Diameter | 2.5" (64 mm) |
| Dipper Cylinder Diameter | 2.25" (57 mm) |
| Bucket Cylinder Diameter | 2" (51 mm) |
| Number of Swing Cylinders | 1 |
| Swing Cylinder Diameter | 2.5" (64 mm) |
| Stabilizer Cylinder Diameter | 2" (51 mm) |
| Reach from Swing Post | 100" (254 cm) |
| Includes Flow Divider | No |
| Bucket Rotation | 180° |
| Swing Arc | 150° |
| SAE* Dipper Boom Digging Force | 1250 lbs (567 kg) |
| SAE* Bucket Digging Force | 2054 lbs (932 kg) |
| Boom Lift Capacity | 250 lbs (113 kg) |
| Ground Clearance | 8.5" (22 cm) |
| Loading Height | 62" (158 cm) |
| Overall Operating Height (Fully Raised) | 91" (231 cm) |
| Includes Hydraulic Hoses and Couplers | Yes |
| Total Weight | 500 lbs (227 kg) |
| Transport Dimensions (LxWxH) | 56" x 41" x 65" (142 cm x 104 cm x 165 cm) |
| Operating Pressure | 1800 psi (12411 kPa) |
| Mounting System | Subframe |
Prices are in Canadian dollars, plus HST, and are subject to change without notice.
