Telescopic Handler Bucket - EXTRA HIGH VOLUME
The HLA Telescopic Handler Bucket - EXTRA HIGH VOLUME is part of the HLA Buckets line, built by Horst Welding in Listowel, Ontario. The range covers 5 sizes and part numbers — see the specifications below.
About the Telescopic Handler Bucket - EXTRA HIGH VOLUME
The Telescopic Handler Bucket - EXTRA HIGH VOLUME (THMBHVX84) is built by Horst Welding in Listowel, Ontario. It is offered in 5 part numbers, covering the sizes in the specifications table below. Factory options are listed in the table as well.
New HLA attachments are supplied through Valtek. Tell us the machine you run and we will match the Telescopic Handler Bucket - EXTRA HIGH VOLUME and its mount to it and price it out.
Features
- 1/4" material, 1/4" end plates
- 3/4 X 6 bevelled cutting edge
- Reinforced top lip
- 55" deep, 46" high
- 3/4 x 8 bolt-on double bevel edge optional
- Drilled for standard bolt on cutting edge
- NOTE: Add 2" to Inside Width column to calculate outside width of bucket
Specifications
| Part Number | Description | INSIDE WIDTH INCHES | STRUCK CAP. CU. YD. | SAE HEAPED CAP. CU. YD. | APPROX. WEIGHT LBS. |
|---|---|---|---|---|---|
| THMBHVX84 | 84" Extra High Volume Telescopic Handler Bucket | 84 | 2.5 | 3.1 | 1505 |
| THMBHVX96 | 96" Extra High Volume Telescopic Handler Bucket | 96 | 2.8 | 3.5 | 1640 |
| THMBHVX108 | 108" Extra High Volume Telescopic Handler Bucket | 108 | 3.2 | 4 | 1750 |
| 348CEB | Optional 348CEB 3/4 X 8 Double Bevel Bolt On Cutting Edge c/w Bolts & Nuts | ||||
| 346CESB | Optional 346CESB 3/4 X 6 Single Bevel Serrated Bolt On Cutting Edge c/w Bolts & Nuts |
Price: Call for pricing
Get a price on the Telescopic Handler Bucket - EXTRA HIGH VOLUME
New HLA attachments supplied through Valtek. Tell us what machine you run and we will match the attachment and mount to it. Call for pricing.
