Jawbone 4-in-1 Buckets
The Jawbone is a 4-in-1 excavator bucket that digs, grades, grips and works as a clamshell. It looks like a regular digging bucket, but a hydraulic rotary actuator inside the crossbar gives it the holding power of a hydraulic thumb, with no custom installation. It handles logs, rocks and scrap,.
About the Jawbone 4-in-1 Buckets
The Jawbone is a 4-in-1 excavator bucket that digs, grades, grips and works as a clamshell. It looks like a regular digging bucket, but a hydraulic rotary actuator inside the crossbar gives it the holding power of a hydraulic thumb, with no custom installation. It handles logs, rocks and scrap, and it can load and dump straight down, which suits swampy material handling.
Two different cutting edges on one bucket let the operator switch between digging and ditching without changing buckets. The grip holds through the full rotation of the bucket, right to roll out, which suits demolition picking, sorting and transferring. The Jawbone Compact brings the same design to smaller excavators.
Features
- 4-in-1 design: digs, grades, grips and clamshells
- Helical actuator in the crossbar, with holding strength up to 54,000 ft-lb of torque at 3,000 PSI
- Constant grip through the full bucket rotation
- Built using Hardox 450 steel, with serrated side plates standard
- Enclosed hydraulics: no cylinders and no exposed hydraulics to damage
- Two cutting edges on one bucket for digging and ditching
Models: Jawbone and Jawbone Compact. AMI's specification tables include a Fast Track column showing Fast Track availability per model.
Specifications
| Machine class (Jawbone) | 24,000 to 65,000 lbs |
| Machine class (Jawbone Compact) | 10,000 to 24,000 lbs |
| Widths (Jawbone) | 24 to 54 in. |
| Capacity (Jawbone) | 0.455 to 1.5 yd3 |
| Capacity (Jawbone Compact) | 4.5 to 10.125 ft3 |
| Weight | 500 to 3,540 lbs |
| Actuator holding torque | Up to 54,000 ft-lb at 3,000 PSI |
